Huffman Coding

R96944043 周伯相

http://www.cmlab.csie.ntu.edu.tw/~zho/

Information Theory and Coding Technique – Programming Homework I

Objective

Design the optimum Huffman Table for the given data source .
Implement effective Huffman Encoder & Decoder.

Requirement

• Build a Huffman Table, and write Symbol Prob. Codeword to a txt file R96944043_HuffT.txt line by line.

Symbol	Probilities	Codeword
0	0.222	0101
...	...	...

• Huffman Encoder, an executable win32 program and show the compression ratio.

>R96944043_HEnc.exe [HuffmanTableFile] [InputFile] [OutputFile]

R96944043:Compression_Ratio: 1.05 %

• Huffman Decoder, an executable win32 program and show the decompression speed.

>R96944043_HDec.exe [HuffmanTableFile] [InputFile] [OutputFile]

R96944043:Dec_Speed: 15 ms

Report

Basic idea: Using shorter codes for the most frequently occurring symbol.
Build Huffman tree:

1. Order the symbols according to their probabilities.
2. Apply a contraction process to the two symbols with the smallest probabilities. Replace them by a hypothetical symbol ,has a probability which is sum of these two smallest probabilities.
3. Repeat the step 1 until the final set has only contain one member.

Program: HuffmanTable.exe

Considering for the data sources, which are gray image files, the contain value is 0 to 255. For general use of Huffman table, I use byte for the symbol, so the codeword number will be 256.
I write the program to create Huffman Table. The program reads a HuffmanTable.ini file to get the data sources, and calculate the probabilities of the frequently occurring symbols, build Huffman tree and find codeword and codeword length.

Test Result:

Test	Data source	Average Codeword Length	Codeword Number
1	test1.bmp(469KB)	7.363922	256
2	test2.bmp(469KB)	7.586709	256
3	test1.bmp & test2.bmp	7.698559	256

Program: R96944043_HEnc.exe

Test Result:

Huffman Table (build from data source)	Input	Output	Compression Ratio
test1.bmp	test1.bmp	test1_R96944043.huf	108.637627 %
test1.bmp	test2.bmp	test2_R96944043.huf	88.018486 %
test2.bmp	test1.bmp	test1_R96944043.huf	96.541534 %
test2.bmp	test2.bmp	test2_R96944043.huf	105.447510 %
test1.bmp & test2.bmp	test1.bmp	test1_R96944043.huf	105.084961 %
test1.bmp & test2.bmp	test2.bmp	test2_R96944043.huf	102.771591 %

Because we can use only one Huffman Table, so I chose test 3 for the final table.

Program: R96944043_HDec.exe

I implement the algorithm of paper “Memory efficient and high-speed search Huffman coding” to speed up decoding time.

• Build single growing Huffman tree.
• Every n level of tree builds a look up table(LUT), each LUT had n*2 rows.
• Fill every index of tree node to LUT.

Test Result:

Input	Output	Decompression Speed(SGH)	Decompression Speed (LUT 4 Level)	Decompression Speed (LUT 8 Level)
test1_R96944043.huf	test1.dec.bmp	12.451862 ms	7.612420 ms	5.357385 ms
test2_R96944043.huf	test2.dec.bmp	14.964751 ms	8.689652 ms	6.182909 ms
test1_R96944043.huf	test1.dec.bmp	14.731202 ms	8.691328 ms	6.568712 ms
test2_R96944043.huf	test2.dec.bmp	13.040205 ms	8.123938 ms	5.858007 ms
test1_R96944043.huf	test1.dec.bmp	12.751062 ms	7.680864 ms	5.530312 ms
test2_R96944043.huf	test2.dec.bmp	13.211456 ms	8.298820 ms	6.009144 ms

I chose LUT 8 Level in my Huffman decoder for best speed.

References

• R. Hashemian, Memory efficient and high-speed search Huffman coding, IEEE Transactions on Communications, vol. 43, no. 10, pp. 2576-2581, October 1995.
